Interfacing with Dakota#

Dakota header

Note

If you would like to get started with using DYNO with Dakota, we encourage you to read the Dakota documentation first, as you will have to set up a case study with Dakota as your first step.

Note

If you are already familiar with both Dakota and DYNO, you can refer to the examples/dakota folder for some reference workflows.

Introduction#

DYNO provides launch, pre- and post-processing capabilities to speed up the interfacing of your simulation with Dakota. This is achieved through the Python interface for DYNO, which is in charge of processing the DYNO configuration files through the Dakota preprocessor, spawning the DYNO executable with the required parameters and performing all post-processing steps required for Dakota to parse simulation outputs.

An example Dakota workflow with DYNO#

Here we provide an example workflow in which:

  1. DYNO will feed a configuration template to the Dakota preprocessor for substitution

  2. Dakota will launch the DYNO simulation

  3. DYNO will postprocess the results to extract the quantities of interest.

In most cases, you will be using Dakota with DYNO to run a large number of simulations. DYNO provides a postprocessor which is especially suited for output from Dakota, as long as the Dakota case input file is configured to generate tagged results in a work directory. To take advantage of the postprocessor, the following keywords must be included in your Dakota case file:

interface,
    analysis_drivers (...)
        (...)
        fork
            (...)
            file_save
            work_directory
                named `runs/run`
                directory_tag
                directory_save
                link_files `<your-configuration-file>.json
            verbatim
(...)

  1. Create your Dakota case in a case.in file.

  2. Create a DYNO configuration file template configuration.tpl.json

  3. In your Dakota case.in case file:

    1. Set your analysis_driver to dynokota analysis_driver {scenario} configuration.tpl.json.

    2. Set your ìnput_filtertodynokota input_filter configuration.tpl.json –json-include {PARAMETERS}`

  4. In your DYNO configuration file template:

    1. Substitute the dictionary value for the quantities of interest with the Dakota variables labels under curly brackets (i.e. {variable}).

  5. (Optional) Disable visualization and logging in your configuration.json file

  6. Launch your Dakota case with dakota case.in

Postprocessing the simulation responses#

In most cases, the output of DYNO are timeseries, while most Dakota simulations expect scalar responses. To provide Dakota with the responses, the postprocessor provides some basic filtering function that allow for applying simple statistics to the resulting time series or select specific samples from the time series. The filters are specified directly in the Dakota input file responses block using a custom pattern.

The response functions are matched to a pattern <response>:<filter>. Here <response> is a dot-separated path in the results HDF5 database file relative to the data group, and <filter> is a function chosen from those available in the pydyno.processing.TimeSeriesProcessor class.

Implementing your own filter is easy, it is sufficient to add a new private method to pydyno.processing.TimeSeriesProcessor with signature _myfilter(self, x).

    @staticmethod
    def _myfilter(self, x):

        return mylibrary.myfilterfunction(x)

You will then be able to apply the filter by specifying <response>:myfilter in the Dakota case file:

(...)
responses,
    response_functions 1
    descriptors 'velocity.linear.x:myfilter'
    no_gradients
    no_hessians

As an example, if you would like to extract the speed of the vehicle at the end of the simulation, you may specify a descriptor velocity.linear.x:end for your response function.

Using Dakota with DYNO and DYNO::ROS#

If you are interested in running Dakota alongside DYNO ROS, you have two choices.

  1. Install Dakota on the host and configure it to spawn a Docker container with DYNO ROS (challenging and fragile).

  2. Create a specialized Docker image from ghcr.io/au-agv/dyno:ros-runtime.

In the first case, you will need some special logic to spawn a Rosbag logger and capture end of a simulation (e.g. via the Docker Compose argument --abort-on-container-exit), and if your simulations are quite brief, the starting and stopping of the containers will be a significant bottleneck.

Because of the above, we recommend building your own Docker image instead. In doing so, you are also able to include any other ROS package in the Docker build (e.g. your navigation stack) as well as any custom message, services and action definitions that may be required by the Rosbag recorder.

If you are able to provide a ROS launch file for your simulation, we provide a launcher that can be used with Dakota specifically when working DYNO ROS. The launcher is enabled by append the keyword ros to the dynokota executable. The command line arguments (detailed in the executable help) follow similar patterns as the normal dynokota executable:

interface,
    id_interface = 'DYNO_INTERFACE'
    analysis_drivers 'dynokota ros analysis_driver'
        input_filter 'dynokota ros input_filter case.tpl.json --json-include {PARAMETERS} --output case.json'
        output_filter 'dynokota rosoutput_filter {PARAMETERS} case.h5 {RESULTS}'

Using exported Dakota surrogate models#

Caution

You need a Dakota Python installation to use the Dakota bindings in the Python package. This is only required for surrogate models evaluation. There is currently no workaround for this in Poetry, as all dependencies must be resolvable. If you would like to use Dakota Python bindings, you will have to explicitly uncomment the following sections under pyproject.toml:

# ---------------------------------------------------------------------------- #
# Dakota dependencies group
# ---------------------------------------------------------------------------- #

#[tool.poetry.group.dakota]
#optional = true

#[tool.poetry.group.dakota.dependencies.dakota]
#path = "/usr/local/share/dakota/Python/dakota"
#optional = true
